Automatic Screen Printing Machine for Caps Side Wall

Automatic Screen Printing Machine for Caps Side Wall

br br This auto printing press system is specially used for printing different patterns on the objects with round shape or oval shape. As it is made up of several individual units to form a printing chain, it can be used for the purpose of one-color printing. The materials to be printed can be plastic, glass, ceramics, metal, etc . br Advantages: br 1 Automatic single color screen printer on Bottle caps; br 2 High efficiency, Auto Feeding, Flame Treatment , Auto Loading and Screen printing as well as UV drying all in one function. br 3 Online Flame Treatment. br 4 Reliable PLC control & touch screen operation system. br 5 Closed working system, well safety protection: br 6 Promise of quality with SMC, FESTO pneumatic parts and Omron, Siemens Electric parts. br 7 High quality aluminium alloy ensure light and ruggedization br Specification br 1.Printing speed: 4000-5000Pcshr br 2.Printing diameter:Round Dia φ15~φ60mm br 3.Printing objects length: 20~200mm br 4.Compress air:0.6~0.8MPa: br 5.Burning oil air: 0.15MPa br 6.Main machine dimension: 260*160*280CM br 7.Power: 3KW,220V br 8.Packing Size: 2 Wooden Case br 1)Wooden Case Size:150*115*193CM(Main Part) br 2)Wooden Case Size:270*125*120CM(Upload System) br br Company: EC Printing Machine Factory Limited br Tel:+86-755-81736312 br Fax:+86-755-81736318 br Website 1: www.printer-manufacture.com br Website 2: www.ecpnp.com br Email 1: sales@printer-manufacture.com br Email 2: sales@ecpnp.


User: EC Printing Machine Factory Limited

Views: 2

Uploaded: 2014-12-07

Duration: 02:45
