KEY FEATURES br  Powered with Kirloskar Ashok Leyland Engine br  Chain – Renold Diamond br  Hydraulic Cylinder – Tafe Dental br  Screed Plate Hardox – 400 S.S br  Stearing Unit Sauer Danfoss br  Auger Diameter – 300 mm (Ni – Hard Material) br  Tyre – Ceat J.K. br  Battery – Amaron Exide br  Priority Valve Provision br br Technical Specifications br MODEL AEP 4.5 HES ( HOT MIX ) AEP 4.5 HES (WET MIX ) br Material Suitability Bituminous Material Bituminous , Wet Mix br Operating Height 3010 mm 3010 mm br Shipping Height 2200 mm 2200 mm br Length 5600 mm 5600 mm br operating width 3050 mm 3050 mm br Shipping width 2750 mm 2750 mm br Weight ( Approx. ) 9.5 tons 10 ton br Truck Dumping Clearance 600 mm 600 mm br Wheel Base 2500 mm 2500 mm br Engine Base br Kirloskar BS III Model 4R1040TC br or Equivalent br Leyland BS III model ALHT4CTIC3 br Kirloskar BS III Model R1040TA3 br or Equivalent br Engine Output 76 HP @ 2200 rpm 105 HP @ 2200 rpm br Battery 12 Volts ( Heavy Duty ) 12 Volts ( Heavy Duty ) br Tyres : Front 2 nos.- Solid Rubber 558 * 405 * 305 mm 558 * 405 * 305 mm br Tyres : Rear 2 nos.- Pneumatic 12*20-18 ply 12*20-18 ply br Paving Thickness 10-200 mm 10-200 mm br Paving Speed 1.25-23 meters 1.25-23 meters br Paving Width br 2.5 - 4.5 meters ( Hydraulically br Extendable Screed ) br 2.5 - 4.5 meters ( Hydraulically br Extendable Screed ) br Travel Speed 0-16 KMPH 0-16 KMPH br Steering Power Steering Power Steering br Hopper Capacity ( Approx. ) 4 Cubic Meters 4 Cubic Meters br Fuel Tank Capacity 120 Litres 120 Litres br Hydraulic Oil Tank Capacity 60 Litres 60 Litres br Screed Heating 2 Nos. Oil Burner or LPG 2 Nos. Oil Burner or LPG br Auger Diameter 300 mm 300 mm br Screed Vibration 0-30 Hz 0-30 Hz br Crown -TO1+3 -TO1+3 br Standard Accessories Tool Box Tool Bo br br br Brief Description br br br Model :-AEP - 45 HES Dual Applicable br Engine: Kirloskar Model - 4R1040 Turbo - 105 br HP Ashok Leyland Model - AL400C2 br Paving Width :2.5 to 4.5 M br Screed: Hydraulically Extendable Vibratory Screed br Model: AEP 45HES Hot Mix br Engine: Kirloskar Model - 4R104076 HP br Paving Width :2.5 to 4.
