br "**UT2311G-AE3-R-VB**br br br br - **Brand:** VBsemibr - **Parameters:**br - Package type: SOT23br - Channel type: P-Channelbr - Maximum withstand voltage: -30Vbr - Maximum drain current: -5.6Abr - On-state resistance (RDS(ON)): 47mΩ @ VGS=10V, VGS=20Vbr - Threshold voltage (Vth): -1Vbr br - **Application introduction:**br UT2311G-AE3-R-VB is a P-Channel power MOSFET packaged in SOT23. Its design features include low on-state resistance and suitability for load switching and power management applications. br br - **Detailed parameter description: **br 1. **Package Type: ** SOT23, which is a small surface mount package suitable for dense circuit board design. br 2. **Channel Type: ** P-Channel, indicating that this is a P-channel MOSFET. br 3. **Maximum Drain-Source Voltage: ** -30V, which is the maximum drain voltage that the device can withstand. br 4. **Maximum Drain Current: ** -5.6A, indicating the maximum drain current that can pass. br 5. **On-state resistance (RDS(ON)): ** 47mΩ @ VGS=10V, VGS=20V, indicating the maximum value of the on-state resistance under a given gate-source voltage. br 6. **Threshold Voltage: ** -1V, which is the gate-source voltage at which the device starts to conduct. br br - **Application Areas:**br 1. **Load Switching:** Applicable to load switching circuits to provide reliable switching control, such as load switches for power management units (PMUs). br 2. **Power Management Modules:** Can be used to build power management modules such as power switches and current controllers. br br - **Module Application Examples:**br 1. **Power Switching Module:** UT2311G-AE3-R-VB can be used to design power switching modules, which are widely used in portable devices and power management systems. br 2. **Power Management Unit (PMU):** As part of the PMU, it is used to control the switching of the power supply and provide efficient power consumption management. br br Please note that the above information is only a general explanation and application suggestion for the given parameters. The circuit requirements and system specifications need to be considered in the specific design.
