Analytical Model in Revit – Essential Skillbr The Analytical Model in Revit is used for structural and energy analysis, helping engineers understand how a building will perform under loads and forces. It is a simplified representation of the physical model used for analysis and simulations.br br 1. What is an Analytical Model in Revit?br The Analytical Model is a simplified version of structural elements (beams, columns, walls, slabs) that helps with:br ✅ Structural Analysis – Load distribution, stress calculations.br ✅ Energy Analysis – Heat loss, solar gain, HVAC loads.br ✅ Coordination with Structural & MEP Engineers – Export to analysis software.br br 📌 Tip: The Analytical Model exists inside the Structural Discipline in Revit.br br 2. Enabling the Analytical Modelbr A) Check if Analytical Model is Enabledbr Select a Structural Element (Wall, Floor, Beam, Column).br In Properties, look for "Enable Analytical Model" and make sure it is ON.br Go to Manage Tab → Structural Settings → Analytical Model Settings to adjust tolerances.br 📌 Tip: You can turn the analytical model ONOFF per element or control it for the entire project.br br 3. Viewing the Analytical Modelbr Go to View Tab → Visibility Graphics (VG).br Under Model Categories, enable "Analytical Model Categories".br Switch to "Analytical Model" View in 3D or Elevations to see only the analytical lines.br 📌 Tip: Analytical elements appear as simplified lines, representing forces and connections.br br 4. Adjusting & Editing the Analytical Modelbr ✅ Manually Adjust Elements:br br Select an analytical element → Use Move, Align, or Trim tools.br Adjust Nodes & Connections to fix errors.br ✅ Set Load Conditions:br Select an analytical element → Go to Properties → Analytical Properties.br Define Load Cases, Supports, and Boundary Conditions.br 📌 Tip: Use "Analytical Adjustments" to modify model behavior before exporting to analysis software.br br 5. Exporting the Analytical Model to Structural Softwarebr A) Export to Robot Structural Analysisbr Go to Analyze Tab → Structural Analysis.br Click "Robot Structural Analysis" to export the model.br Perform analysis in Robot and send results back to Revit.br B) Export to Other Software (SAP2000, ETABS, StaadPro)br File → Export → Structural Analysis Format (SAF) or IFC.br Import into ETABS, StaadPro, or SAP2000 for further calculations.br 📌 Tip: Always review the analytical model for connectivity issues before exporting.br br 6. Analytical Model for Energy Analysisbr ✅ Used for HVAC load calculations, daylight studies, and thermal performance.br ✅ Enabled via Energy Settings:br br Go to Analyze Tab → Energy Optimization.br Define Building Envelope, Insulation, and Heat Gains.br ✅ Send model to Insight 360 or Green Building Studio for energy simulations.br 📌 Tip: Ensure analytical surfaces are properly assigned for accurate results.br br 🚀 Quick Summary:br 🔹 Analytical Model = Simplified representation of structural and energy performance.br 🔹 Enable in Structural Settings & Visibility Graphics (VG).
