Editing Profile Viewbr br 1. Select the profile view: Choose the pressure network profile view you want to edit.br 2. Properties palette: Open the Properties palette (Ctrl + 1).br 3. Modify properties: Edit profile view properties, such as station range, elevation range, and labels.br br Modifying Profile View Stylebr br 1. Edit profile view style: Go to the "Settings" tab "Profile View Styles" "Edit Profile View Style".br 2. Modify style properties: Change the profile view style's appearance, such as layout, labels, and grid.br br Updating Profile Databr br 1. Update profile data: If the pressure network changes, update the profile data by regenerating the profile view.br br Label Editingbr br 1. Edit labels: Modify label properties, such as text, location, and format.br br Other Editing Optionsbr br 1. Move resize profile view: Adjust the profile view's position and size.br 2. Add remove labels: Add or remove labels as needed.
